FRAME 3 - F03-3

FRAME 3 - F03-3

No.

01
P/N (SKU): 6GUV-030190-3000-0DN00
Part Name: MUFFLER REAR RH DECO COVER
Effective: 2025-11-27
Remarks: null
Alternative parts: null
Specification: CERAMIC BLACK
Price: 18,00 € : 18,00 €
-+
02
P/N (SKU): 6GUV-021006-5600
Part Name: INNER HEX STEPPED SCREW
Effective: 2025-11-27
Remarks: null
Alternative parts: null
Specification: M6×12
Price: 1,50 € : 1,50 €
03
P/N (SKU): 6AQV-021004-3001
Part Name: GUARD RUBBER SLEEVE
Effective: 2025-11-27
Remarks: null
Alternative parts: null
Specification: null
Price: 3,50 € : 3,50 €
-+
04
P/N (SKU): 6GUV-030170-3000
Part Name: MUFFLER RH DECO COVER BRACKET
Effective: 2025-11-27
Remarks: null
Alternative parts: null
Specification: null
Price: 7,00 € : 7,00 €
05
P/N (SKU): 6WWV-046702-5000
Part Name: INNER HEX SCREW M6x12
Effective: 2025-11-27
Remarks: null
Alternative parts: 6WWV-046802-5000
Specification: null
Price: 1,50 € : 1,50 €
06
P/N (SKU): 30006-060012810
Part Name: HEXAGON FLANGE BOLTS
Effective: 2025-11-27
Remarks: null
Alternative parts: 30006-060012870
Specification: M6×12
Price: 1,50 € : 1,50 €
07
P/N (SKU): 6GUV-030160-3000
Part Name: MUFFLER LH DECO COVER BRACKET
Effective: 2025-11-27
Remarks: null
Alternative parts: null
Specification: null
Price: 7,00 € : 7,00 €
08
P/N (SKU): 6GUV-030180-3000-0DN00
Part Name: MUFFLER REAR LH DECO COVER
Effective: 2025-11-27
Remarks: null
Alternative parts: null
Specification: CERAMIC BLACK
Price: 18,00 € : 18,00 €
-+
09
P/N (SKU): 6L30-030071-10000
Part Name: SPRING SLEEVE, SIDE BRACKET
Effective: 2025-11-27
Remarks: null
Alternative parts: null
Specification: null
Price: 3,00 € : 3,00 €
10
P/N (SKU): 6GUV-030400-5600-0BP00
Part Name: SIDE STAND ASSY
Effective: 2025-11-27
Remarks: null
Alternative parts: null
Specification: MAUD SPIRIT BLACK
Price: 15,00 € : 15,00 €
11
P/N (SKU): 6L30-030050
Part Name: SPRING, SIDE BRAKCET
Effective: 2025-11-27
Remarks: null
Alternative parts: null
Price: 6,00 € : 6,00 €
-+
12
P/N (SKU): 30208-102010
Part Name: HEXAGON THIN NUTS
Effective: 2025-11-27
Remarks: null
Alternative parts: null
Specification: M10×1.25
Price: 1,50 € : 1,50 €
-+
13
P/N (SKU): A000-030006
Part Name: SIDE BRACKET BOLT
Effective: 2025-11-27
Remarks: null
Alternative parts: null
Price: 2,50 € : 2,50 €
-+
