MIDDLE PLASTICS(FOR NON SIDE DOORS) - F04-3-B-V4

MIDDLE PLASTICS(FOR NON SIDE DOORS) - F04-3-B-V4

No.

01
P/N (SKU): 5HY#-042021-6000-10
Part Name: REAR UPPER LH PANEL
Effective: 2021-04-16
Alternative parts: 5HYV-042021-1D00
Price: 13,00 € : 13,00 €
02
P/N (SKU): 5HY#-042022-6000-10
Part Name: REAR RH UPPER SIDE PANEL
Effective: 2021-04-16
Alternative parts: 5HYV-042022-1D00
Price: 13,00 € : 13,00 €
03
P/N (SKU): 5HY0-042023
Part Name: REAR LH PANEL
Effective: 2021-04-16
Alternative parts: 5HYV-042023-1C00
Price: 55,00 € : 55,00 €
04
P/N (SKU): 5HY0-042024
Part Name: REAR RH SIDE PANEL
Effective: 2021-04-16
Alternative parts: 5HYV-042024-1C00
Price: 53,00 € : 53,00 €
05
P/N (SKU): 5HY0-042025
Part Name: MOUNT COVER, LH HINGE
Effective: 2021-04-16
Price: 2,50 € : 2,50 €
-+
06
P/N (SKU): 5HY0-042026
Part Name: MOUNT COVER, RH HINGE
Effective: 2021-04-16
Price: 2,50 € : 2,50 €
-+
07
P/N (SKU): 5HY0-042028
Part Name: RH AIR INLET PORT DEFLECTOR
Effective: 2021-04-16
Price: 8,00 € : 8,00 €
-+
08
P/N (SKU): 5HY0-042030
Part Name: FILTER
Effective: 2021-04-16
Price: 5,00 € : 5,00 €
-+
09
P/N (SKU): 5HY0-042027
Part Name: DEFLECTOR, LH
Effective: 2021-04-16
Price: 9,00 € : 9,00 €
-+
10
P/N (SKU): 5HY#-043051-1000
Part Name: LH FOOT PEDAL
Effective: 2021-04-16
Alternative parts: 5HYV-043051-1C00
Price: 39,00 € : 39,00 €
11
P/N (SKU): 5HY#-043052-1000
Part Name: RH FOOT PEDAL
Effective: 2021-04-16
Alternative parts: 5HYV-043052-1C00
Price: 40,00 € : 40,00 €
12
P/N (SKU): 5HY0-043053
Part Name: SERVICE COVER, FOOT PEDAL
Effective: 2021-04-16
Price: 44,00 € : 44,00 €
-+
12
P/N (SKU): 5HYV-043053-1000
Part Name: SERVICE COVER, PEDAL
Effective: 2021-04-16
Alternative parts: 5HYV-043053-1001
Price: 44,00 € : 44,00 €
13
P/N (SKU): 5HY#-043061-1000-11
Part Name: FRONT LOWER BAFFLE, SEAT
Effective: 2021-04-16
Remarks: FOR NON HEATING EQUIPMENT SEAT
Price: 46,00 € : 46,00 €
-+
13
P/N (SKU): 5HY#-043061-1000-10
Part Name: FRONT LOWER BAFFLE, SEAT
Effective: 2021-04-16
Remarks: FOR HEATING EQUIPMENT SEAT
Price: 46,00 € : 46,00 €
-+
14
P/N (SKU): 9060-040310
Part Name: CLAMP ASSY
Effective: 2021-04-16
Price: 2,00 € : 2,00 €
-+
15
P/N (SKU): 8010-000004
Part Name: BOLT M6x14
Effective: 2021-04-16
Specification: M6x14
Price: 1,50 € : 1,50 €
-+
16
P/N (SKU): 0180-015003
Part Name: RUBBER SLEEVE
Effective: 2021-04-16
Price: 1,50 € : 1,50 €
-+
17
P/N (SKU): 30006-080016810
Part Name: HEXAGON FLANGE BOLTS
Effective: 2021-04-16
Specification: M8x16@COLOR ZINC TRIVALENT CHROMIUM
Price: 1,50 € : 1,50 €
-+
18
P/N (SKU): 30006-060010810
Part Name: HEXAGON FLANGE BOLTS
Effective: 2021-04-16
Specification: M6×10
Price: 1,50 € : 1,50 €
-+
19
P/N (SKU): 8030-040800
Part Name: NUT CLIP M6
Effective: 2021-04-16
Alternative parts: 8030-040800-00001
Specification: M6
Price: 1,50 € : 1,50 €
20
P/N (SKU): 8010-000005
Part Name: BOLT M6x17
Effective: 2021-04-16
Alternative parts: 8010-000005-1000
Specification: M6x17
Price: 1,50 € : 1,50 €
21
P/N (SKU): 30110-480160010
Part Name: CROSS-RECESSED FLAT ROUND HEAD TAPPING SCREWS
Effective: 2021-04-16
Specification: ST4.
Price: 1,50 € : 1,50 €
-+
22
P/N (SKU): 5020-040049
Part Name: CLAMP ST4.8
Effective: 2021-04-16
Specification: ST4.8
Price: 1,50 € : 1,50 €
-+
23
P/N (SKU): 5HY0-043001
Part Name: BOLT
Effective: 2021-04-16
Alternative parts: 6NQ#-000202-6001
Price: 2,50 € : 2,50 €
24
P/N (SKU): 6NQ#-000206-6001
Part Name: INNER HEX SCREW M6x16
Effective: 2021-04-16
Specification: M6x16
Price: 1,50 € : 1,50 €
-+
25
P/N (SKU): 5BY0-042032
Part Name: PLUG, PEDAL
Effective: 2021-04-16
Alternative parts: 5BYV-042032-AD00
Price: 1,50 € : 1,50 €
-+
