TRANSMISSION SYSTEM(NEW) - F29-V1

TRANSMISSION SYSTEM(NEW) - F29-V1

No.

01
P/N (SKU): 30204-102840
Part Name: NUT M10x1.25
Effective: 2021-02-26
Alternative parts: 30204-102110
Specification: M10x1.25
Price: 1,50 € : 1,50 €
02
P/N (SKU): 30006-102090810
Part Name: BOLT
Effective: 2021-02-26
Alternative parts:
Specification: M10×1.25×90
Price: 3,00 € : 3,00 €
-+
03
P/N (SKU): 30006-102025810
Part Name: BOLT
Effective: 2021-02-26
Alternative parts:
Specification: M10×1.25×25
Price: 1,50 € : 1,50 €
-+
04
P/N (SKU): 0181-310000
Part Name: CF188 FRONT GEAR CASE ASSY
Effective: 2021-02-26
Alternative parts: Q800-310000-00001
Price: 716,00 € : 716,00 €
05
P/N (SKU): 9010-290001
Part Name: BOLT M8x1x22
Effective: 2021-02-26
Alternative parts:
Specification: M8x1x22
Price: 2,00 € : 2,00 €
-+
06
P/N (SKU): 9010-290100-00001
Part Name: FRONT DRIVE SHAFT
Effective: 2021-02-26
Alternative parts:
Price: 107,00 € : 107,00 €
-+
07
P/N (SKU): 30601-108010
Part Name: CLAMP
Effective: 2021-02-26
Alternative parts:
Specification: A8@COLOR ZINC TRIVALENT CHROMIUM
Price: 1,50 € : 1,50 €
-+
08
P/N (SKU): 9010-310001
Part Name: FRONT GEAR CASE BREATHER HOSE
Effective: 2021-02-26
Alternative parts:
Price: 5,00 € : 5,00 €
-+
09
P/N (SKU): 30006-102110810
Part Name: BOLT M10x1.25x110
Effective: 2021-02-26
Alternative parts: 30006-102110110
Specification: M10x1.25x110
Price: 3,00 € : 3,00 €
10
P/N (SKU): Q500-330000
Part Name: QDW0 REAR GEAR CASE
Effective: 2021-02-26
Alternative parts: 7020-080002+9010-300001+9010-300002+9CR6-300200+9CR6-300206-10000+Q520-330000
Price: 569,00 € : 569,00 €
11
P/N (SKU): 7020-080002
Part Name: REAR BRAKE DISC
Effective: 2021-02-26
Alternative parts:
Specification: FOUR HOLES INSTEAD OF SIX HOLES OF INSTALLATION STRUCTURE
Price: 24,00 € : 24,00 €
-+
12
P/N (SKU): 9010-300001
Part Name: BOLT M10x1.25x30
Effective: 2021-02-26
Alternative parts:
Specification: M10x1.25x30
Price: 2,50 € : 2,50 €
-+
13
P/N (SKU): 9010-300100-10000
Part Name: REAR DRIVE SHAFT
Effective: 2021-02-26
Alternative parts:
Price: 104,00 € : 104,00 €
-+
14
P/N (SKU): 9010-300002
Part Name: WASHER Dia 10
Effective: 2021-02-26
Alternative parts:
Specification: Dia 10
Price: 1,50 € : 1,50 €
-+
15
P/N (SKU): 30306-080142
Part Name: WASHER
Effective: 2021-02-26
Alternative parts: 30306-080112
Specification: 8
Price: 1,50 € : 1,50 €
16
P/N (SKU): 7020-290130-10000
Part Name: UNIVERSAL JOINT Dia 25x64
Effective: 2021-02-26
Alternative parts:
Specification: Dia 25x64
Price: 19,00 € : 19,00 €
-+
18
P/N (SKU): 30800-02505
Part Name: CIRCLIP FOR HOLE A-D25
Effective: 2021-02-26
Alternative parts:
Specification: 25
Price: 1,50 € : 1,50 €
-+
