TRANSMISSION SYSTEM(NEW) - F28-2 | 2016, ATV, CF500-5 |

You are here

No.

P/N (SKU)

Part Name

Price

Your price

01

P/N (SKU): 30204-102840

Part Name: NUT M10x1.25

Effective: 2021-02-26

Alternative parts: 30204-102110

Specification: M10x1.25

Price: 1,50 € : 1,50 €

02

P/N (SKU): 30006-102090810

Part Name: HEXAGON FLANGE BOLTS

Effective: 2021-02-26

Specification: M10Ã1.25Ã90

Price: 3,00 € : 3,00 €

03

P/N (SKU): 30006-102025810

Part Name: HEXAGON FLANGE BOLTS

Effective: 2021-02-26

Specification: M10Ã1.25Ã25

Price: 1,50 € : 1,50 €

04

P/N (SKU): 0181-310000

Part Name: CF188 FRONT GEAR CASE ASSY

Effective: 2021-02-26

Alternative parts: Q800-310000-00001

Price: 716,00 € : 716,00 €

05

P/N (SKU): 9010-290001

Part Name: BOLT M8x1x22

Effective: 2021-02-26

Specification: M8x1x22

Price: 2,00 € : 2,00 €

06

P/N (SKU): 9010-290100-00001

Part Name: FRONT DRIVE SHAFT

Effective: 2021-02-26

Price: 107,00 € : 107,00 €

07

P/N (SKU): 30601-108010

Part Name: STEEL WIRE ELASTIC RING HOOP

Effective: 2021-02-26

Specification: A8@COLOR ZINC TRIVALENT CHROMIUM

Price: 1,50 € : 1,50 €

08

P/N (SKU): 9010-310001

Part Name: FRONT GEAR CASE BREATHER HOSE

Effective: 2021-02-26

Alternative parts: 9010-310001-1000

Price: 5,00 € : 5,00 €

09

P/N (SKU): 30006-102110810

Part Name: HEXAGON FLANGE BOLTS

Effective: 2021-02-26

Alternative parts: 30006-102110110

Specification: M10x1.25x110

Price: 3,00 € : 3,00 €

10

P/N (SKU): Q500-330000

Part Name: QDW0 REAR GEAR CASE

Effective: 2021-02-26

Alternative parts: 7020-080002+9010-300001+9010-300002+9CR6-300200+9CR6-300206-10000+Q520-330000

Price: 569,00 € : 569,00 €

11

P/N (SKU): 7020-080002

Part Name: REAR BRAKE DISC

Effective: 2021-02-26

Specification: FOUR HOLES INSTEAD OF SIX HOLES OF INSTALLATION STRUCTURE

Price: 24,00 € : 24,00 €

12

P/N (SKU): 9010-300001

Part Name: BOLT M10x1.25x30

Effective: 2021-02-26

Specification: M10x1.25x30

Price: 2,50 € : 2,50 €

13

P/N (SKU): 9010-300100-10000

Part Name: REAR DRIVE SHAFT

Effective: 2021-02-26

Price: 104,00 € : 104,00 €

14

P/N (SKU): 9010-300002

Part Name: WASHER Dia 10

Effective: 2021-02-26

Specification: Dia 10

Price: 1,50 € : 1,50 €

15

P/N (SKU): 30306-080142

Part Name: WASHER

Effective: 2021-02-26

Alternative parts: 30306-080112

Specification: 8

Price: 1,50 € : 1,50 €

16

P/N (SKU): 7020-290130-10000

Part Name: UNIVERSAL JOINT Dia 25x64

Effective: 2021-02-26

Specification: Dia 25x64

Price: 19,00 € : 19,00 €

18

P/N (SKU): 30800-02505

Part Name: CIRCLIPS FOR HOLES

Effective: 2021-02-26

Specification: 25

Price: 1,50 € : 1,50 €
