SEAT ASSY - F21

SEAT ASSY - F21

No.

01
P/N (SKU): 9030-180600-1000
Part Name: OIL PIPE ASSY I, ENGINE
Effective: 2021-02-26
Alternative parts:
Price: 12,00 € : 12,00 €
-+
02
P/N (SKU): 9030-180700
Part Name: OIL PIPE ASSY 2, ENGINE
Effective: 2021-02-26
Alternative parts:
Price: 12,00 € : 12,00 €
-+
03
P/N (SKU): 30604-116500
Part Name: CLAMP, HOSE
Effective: 2021-02-26
Alternative parts:
Price: 2,00 € : 2,00 €
-+
04
P/N (SKU): 9030-180020
Part Name: RH OIL PIPE
Effective: 2021-02-26
Remarks: Length:220mm ；is replaced by 9030-180005(350mm-130mm=220mm)
Alternative parts: 9030-180005
Price: 6,00 € : 6,00 €
05
P/N (SKU): 9030-180005
Part Name: OIL PIPE
Effective: 2021-02-26
Alternative parts:
Price: 11,00 € : 11,00 €
-+
06
P/N (SKU): 9030-180003
Part Name: RH STEEL OIL HOSE
Effective: 2021-02-26
Alternative parts:
Price: 20,00 € : 20,00 €
-+
07
P/N (SKU): 9030-180004
Part Name: LH STEEL OIL HOSE
Effective: 2021-02-26
Alternative parts:
Price: 20,00 € : 20,00 €
-+
08
P/N (SKU): 30006-060020840
Part Name: BOLT
Effective: 2021-02-26
Alternative parts: 30006-060020810
Specification: M6x20
Price: 1,50 € : 1,50 €
09
P/N (SKU): 9030-180007
Part Name: CLIP, OIL PIPE
Effective: 2021-02-26
Alternative parts:
Price: 2,00 € : 2,00 €
-+
10
P/N (SKU): 9030-180008
Part Name: RUBBER SLEEVE
Effective: 2021-02-26
Alternative parts:
Price: 1,50 € : 1,50 €
-+
12
P/N (SKU): 9030-180033
Part Name: FRONT OIL PIPE, LH
Effective: 2021-02-26
Alternative parts:
Price: 8,50 € : 8,50 €
-+
13
P/N (SKU): 30006-060025840
Part Name:
Effective: 2021-02-26
Alternative parts:
Price: 1,50 € : 1,50 €
-+
14
P/N (SKU): 5020-031002
Part Name: FRONT LICENSE BRACKET RUBBER SLEEVE BUS
Effective: 2021-02-26
Alternative parts:
Price: 1,50 € : 1,50 €
-+
15
P/N (SKU): 5020-031001
Part Name: RUBBER SLEEVE, FRONT LICENSE BRACKET
Effective: 2021-02-26
Alternative parts:
Price: 2,00 € : 2,00 €
-+
16
P/N (SKU): 9030-181100
Part Name: OIL RADIATOR
Effective: 2021-02-26
Alternative parts:
Price: 144,00 € : 144,00 €
-+
17
P/N (SKU): 9030-180100
Part Name: RADIATOR ASSY
Effective: 2021-02-26
Alternative parts:
Price: 151,00 € : 151,00 €
-+
18
P/N (SKU): 9010-180200-3000
Part Name: FAN@^MOTOR
Effective: 2021-02-26
Alternative parts:
Price: 109,00 € : 109,00 €
-+
19
P/N (SKU): 0010-135000
Part Name: THERMO SWITCH
Effective: 2021-02-26
Remarks: 80±4℃,Non-waterproofed
Alternative parts:
Price: 16,00 € : 16,00 €
-+
20
P/N (SKU): 0180-023500-0030
Part Name: CLAMP, WATER HOSE
Effective: 2021-02-26
Alternative parts: 9010-180007
Price: 3,00 € : 3,00 €
21
P/N (SKU): 9030-180031
Part Name: WATER FILLING PORT HOSE
Effective: 2021-02-26
Alternative parts:
Price: 3,50 € : 3,50 €
-+
22
P/N (SKU): 8030-180001
Part Name: WATER FILLING PORT
Effective: 2021-02-26
Alternative parts:
Price: 3,50 € : 3,50 €
-+
23
P/N (SKU): 8010-180024
Part Name: WATER FILLING PORT CAP ASSY
Effective: 2021-02-26
Alternative parts:
Price: 8,50 € : 8,50 €
-+
23
P/N (SKU): 9030-180200-1000
Part Name: RADIATOR WATER INLET HOSE
Effective: 2021-02-26
Alternative parts:
Price: 15,00 € : 15,00 €
-+
25
P/N (SKU): 9030-180071
Part Name: ADAPTOR, CLIP
Effective: 2021-02-26
Alternative parts:
Price: 1,50 € : 1,50 €
-+
26
P/N (SKU): 9030-180002-1000
Part Name: RH STEEL WATER HOSE
Effective: 2021-02-26
Alternative parts:
Price: 11,00 € : 11,00 €
-+
27
P/N (SKU): 9030-180001-1000
Part Name: LH STEEL WATER PIPE
Effective: 2021-02-26
Alternative parts:
Price: 14,00 € : 14,00 €
-+
28
P/N (SKU): 9030-180009
Part Name: RUBBER COLLAR, WATER HOSE
Effective: 2021-02-26
Alternative parts:
Price: 2,00 € : 2,00 €
-+
29
P/N (SKU): 9030-180006
Part Name: CLASP, WATER HOSE
Effective: 2021-02-26
Alternative parts:
Price: 1,50 € : 1,50 €
-+
30
P/N (SKU): 9030-180500
Part Name: WATER OUTLET PIPE, ENGINE
Effective: 2021-02-26
Alternative parts:
Price: 16,00 € : 16,00 €
-+
31
P/N (SKU): 9030-180400
Part Name: WATER INLET PIPE, ENGINE
Effective: 2021-02-26
Alternative parts:
Price: 18,00 € : 18,00 €
-+
32
P/N (SKU): 9030-180300-1000
Part Name: RADIATOR WATER OUTLET HOSE
Effective: 2021-02-26
Alternative parts:
Price: 15,00 € : 15,00 €
-+
33
P/N (SKU): 9010-180005
Part Name: RESERVOIR OVERFLOW HOSE
Effective: 2021-02-26
Alternative parts:
Price: 8,00 € : 8,00 €
-+
34
P/N (SKU): 30601-108520
Part Name: CLAMP A8.5
Effective: 2021-02-26
Alternative parts: 30601-109010
Price: 2,50 € : 2,50 €
35
P/N (SKU): 9030-181301
Part Name: RESERVOIR WATER PIPE
Effective: 2021-02-26
Alternative parts:
Price: 6,00 € : 6,00 €
-+
36
P/N (SKU): 9030-181200
Part Name: RESERVOIR TANK ASSY
Effective: 2021-02-26
Alternative parts:
Price: 14,00 € : 14,00 €
-+
37
P/N (SKU): 30601-111010
Part Name: CLAMP
Effective: 2021-02-26
Alternative parts:
Specification: A11@COLOR ZINC TRIVALENT CHROMIUM
Price: 1,50 € : 1,50 €
-+
38
P/N (SKU): 30006-060012840
Part Name: BOLT M6x12
Effective: 2021-02-26
Alternative parts: 30006-060012810
Specification: M6x12
Price: 1,50 € : 1,50 €
39
P/N (SKU): 9030-180035
Part Name: SPRING PROTECTOR 1
Effective: 2021-02-26
Remarks: L=170mm
Alternative parts:
Price: 2,50 € : 2,50 €
-+
40
P/N (SKU): 9030-180034
Part Name: SPRING PROTECTOR 2
Effective: 2021-02-26
Remarks: L=320mm
Alternative parts:
Price: 4,00 € : 4,00 €
-+
41
P/N (SKU): 30112-060016440
Part Name: SCREW ASSY
Effective: 2021-02-26
Alternative parts: 30112-060016410
Specification: M6x16@ARMY GREEN
Price: 2,00 € : 2,00 €
42
P/N (SKU): 0180-011006
Part Name: GASKET 14
Effective: 2021-02-26
Alternative parts:
Specification: 14
Price: 1,50 € : 1,50 €
-+
43
P/N (SKU): 8030-040800
Part Name: NUT CLIP M6
Effective: 2021-02-26
Alternative parts: 8030-040800-00001
Specification: M6
Price: 1,50 € : 1,50 €
44
P/N (SKU): 6050-180006
Part Name: RUBBER WASHER 16x23x2
Effective: 2021-02-26
Alternative parts:
Price: 2,00 € : 2,00 €
-+
45
P/N (SKU): 9030-080401
Part Name: RESERVOIR CAP
Effective: 2022-01-10
Alternative parts:
Price: 0,00 € : 0,00 €
-+
