ELECTRIC SYSTEM - F15

ELECTRIC SYSTEM - F15

No.

01
P/N (SKU): A030-150100
Part Name: MAIN CABLE
Effective: 2021-02-26
Price: 192,00 € : 192,00 €
-+
02
P/N (SKU): A000-150200
Part Name: STARTER MOTOR POSITIVE CABLE
Effective: 2021-02-26
Price: 15,00 € : 15,00 €
-+
03
P/N (SKU): A000-150300
Part Name: STARTER MOTOR NEGATIVE CABLE
Effective: 2021-02-26
Price: 15,00 € : 15,00 €
-+
04
P/N (SKU): 9010-150002
Part Name: AUXILIARY RELAY RUBBER RING
Effective: 2021-02-26
Price: 4,50 € : 4,50 €
-+
05
P/N (SKU): 9010-150350
Part Name: AUXILIARY RELAY
Effective: 2021-02-26
Price: 7,00 € : 7,00 €
-+
06
P/N (SKU): 30112-060016440
Part Name: SCREW ASSY
Effective: 2021-02-26
Alternative parts: 30112-060016410
Specification: M6x16@ARMY GREEN
Price: 2,00 € : 2,00 €
07
P/N (SKU): 8030-151400
Part Name: DIVERTER RELAY
Effective: 2021-02-26
Price: 9,50 € : 9,50 €
-+
08
P/N (SKU): 9010-150310-1000
Part Name: STARTER RELAY
Effective: 2021-02-26
Remarks: WITHOUT CABLE
Alternative parts: 9010-150310-10001/9CR6-150310
Price: 25,00 € : 25,00 €
09
P/N (SKU): A000-150700
Part Name: POSITIVE CABLE, STARTER RELAY
Effective: 2021-02-26
Price: 16,00 € : 16,00 €
-+
10
P/N (SKU): 8010-150003
Part Name: TIE BAND
Effective: 2021-02-26
Specification: 5x250
Price: 1,50 € : 1,50 €
-+
11
P/N (SKU): A000-100002
Part Name: CLUTCH CABLE CLIP
Effective: 2021-02-26
Price: 1,50 € : 1,50 €
-+
12
P/N (SKU): A000-050015
Part Name: WIRE CLIP, FRONT BRAKE FLUID HOSE
Effective: 2021-02-26
Price: 1,50 € : 1,50 €
-+
13
P/N (SKU): A000-150600
Part Name: FLASHER
Effective: 2021-02-26
Alternative parts: A000-150600-1000
Price: 6,00 € : 6,00 €
14
P/N (SKU): 8010-150002
Part Name: CUSHION WASHER, FLASHER
Effective: 2021-02-26
Price: 1,50 € : 1,50 €
-+
15
P/N (SKU): 8010-090005
Part Name: BOLT M6x16
Effective: 2021-02-26
Specification: M6x16
Price: 1,50 € : 1,50 €
-+
16
P/N (SKU): 6070-151200-1000
Part Name: SIDE STAND SWITCH
Effective: 2021-02-26
Alternative parts: 6KMV-151200-8501
Price: 8,00 € : 8,00 €
-+
17
P/N (SKU): 6060-150002
Part Name: ROLL-OVER SENSOR SLEEVE
Effective: 2021-02-26
Price: 2,00 € : 2,00 €
-+
18
P/N (SKU): 0060-175000
Part Name: ROLL-OVER SENSOR
Effective: 2021-02-26
Price: 14,00 € : 14,00 €
-+
19
P/N (SKU): 9010-150500
Part Name: REAR BRAKE SWITCH
Effective: 2021-02-26
Price: 11,00 € : 11,00 €
-+
20
P/N (SKU): 30006-060012840
Part Name: BOLT M6x12
Effective: 2021-02-26
Alternative parts: 30006-060012810
Specification: MILITARY GREEN
Price: 1,50 € : 1,50 €
21
P/N (SKU): 0180-014010
Part Name: WIRE CLAMP
Effective: 2021-02-26
Alternative parts: 6WWV-030080-8000
Price: 1,50 € : 1,50 €
-+
22
P/N (SKU): 30006-080014840
Part Name: null
Effective: 2021-02-26
Price: 1,50 € : 1,50 €
-+
23
P/N (SKU): A000-150500
Part Name: ELECTRIC HORN 12V
Effective: 2021-02-26
Price: 9,00 € : 9,00 €
-+
24
P/N (SKU): A000-150003
Part Name: BRACKET, ECU
Effective: 2021-02-26
Price: 7,00 € : 7,00 €
-+
25
P/N (SKU): A000-150002
Part Name: ECU PROTECTOR
Effective: 2021-02-26
Price: 4,50 € : 4,50 €
-+
26
P/N (SKU): 0700-174000-1000
Part Name: ECU
Effective: 2021-02-26
Remarks: Used together with 0700-173000-1000(throttle body with hole)
Price: 684,00 € : 684,00 €
-+
27
P/N (SKU): 31021000
Part Name: BATTERY
Effective: 2021-02-26
Remarks: is replaced by 31021001
Alternative parts: 31021200
Specification: 12V10Ah
Price: 83,00 € : 83,00 €
28
P/N (SKU): 01AA-177000
Part Name: REGULATOR
Effective: 2021-02-26
Specification: 330W
Price: 104,00 € : 104,00 €
-+
29
P/N (SKU): 30006-060030840
Part Name: BOLT M6x30
Effective: 2021-02-26
Alternative parts: 30006-060030810
Specification: MILITARY GREEN
Price: 1,50 € : 1,50 €
30
P/N (SKU): 0060-176000
Part Name: OXYGEN SENSOR
Effective: 2021-02-26
Price: 157,00 € : 157,00 €
-+
31
P/N (SKU): 0700-178000
Part Name: IGNITION COIL
Effective: 2021-02-26
Price: 85,00 € : 85,00 €
-+
32
P/N (SKU): A010-150001
Part Name: SPRING, REAR BRAKE SWITCH
Effective: 2021-02-26
Price: 1,50 € : 1,50 €
-+
